Project | Parameter | Project | Parameter |
Card reader type | EM card or Mifare card | Barcode type | QR CODE, one dimensional code |
communication method | Wiegand 26/34/RS232/RS485/USB | Decoding mode | Image decoding |
Reading direction (bar code) | Angle 45° with the lens as the center point | Scan code characteristics | Automatic induction, buzzer prompt |
Operating Voltage | 4-15V | Working current | <0.75W |
Card reading distance (card) | 0~10CM | Reading speed | <200ms |
Reading distance (QR code) | 0-20cm | Material quality | ABS + acrylic panel |
Working humidity | 10%~90% | Operating temperature | -30℃~70℃ |
Size | 86*86*8mm | Weight | 150G |
