| AD86 QR code access control reader | ||||||||
| Specifications | ||||||||
| Input Voltage | Wide Range DC12V | |||||||
| Operating Current | ≤80mA | |||||||
| User Capacity | Zone one: 1100 users/Zone two: 100 users | |||||||
| Proximity Card | EM Card 125Khz | |||||||
| Reading range | 4-6cm | |||||||
| Wiegand range | Wiegand 26 input & output | |||||||
| Operating temperature | -40~70℃ | |||||||
| Operating Humidity | 10%-98% | |||||||
| Dimension | 110×76×22mm | |||||||
